Description

Redashe Hedson IRT UV SmartCure Rechargeable Hand Held Battery-Powered UV Curing Lamp (R715070 IRT)

The UV Smartcure is a robust hand held battery-powered UV curing device developed using the decades of experience of curing paints of all types with UV & Infra-red lamps. It combines the latest UV LED technology. Constructed from a tough glass fibre filled polymer, the unit is fitted with a 3mm scratch solvent resistant tempered glass with a fibre reinforced frame to prevent damage, to the units high performance UV-LED. The electronics have been designed specifically for this unit and include an intuitive, user-friendly display that shows the battery level, run time & when the fan is running. They also include temperature sensors to guarantee that neither the electronics or LEDs, can overheat. The kit includes 2 high performance 18V Lithium-ion rechargeable batteries (fast charge 45 minutes), 1 battery charger, 1 wall mount, & a pair of UV Safety glasses.

SmartCure comes with two exchangeable batteries and cures UV-A filler and primer in seconds, available for 365 nm/ 395 nm.

IRT UV SmartCure has an extremely powerful output, offering market leading peak/average light intensity.

By combining a powerful UV-LED-module, advanced cooling technology and light weight batteries, reliable, highly effective, non-fluctuating UV-curing is achieved.

Advanced electronics minimizes the risk of machine damage by active ventilation and by monitoring the temperature of both electronics and LED-module. This provides safe operation with efficient steady state voltage LED-output and current control regulation.

ELIMINATE DOWNTIME
With two exchangeable 18V lithium-ion batteries and 45 minute charging time, IRT UV SmartCure is always available.

RELIABLE CURING RESULTS
By working closely with leading paint manufacturers IRT enables reliable paint processes in all bodyshops.

ULTIMATE CURING GUIDE
To obtain peak performance, work at appr 100 mm from surface. @ filler/primer thickness 80-120 µm, Ø 160 mm is cured in appr 10 sec. (Peak light intensity >350 mW/cm2, average >250 mW/m2).

Features

• Fast curing time
• Easy to use
• Low-temperature processing
• Minimal maintenance
• Safe to use in your bodyshop
• Included in kit: 1x IRT UV Smartcure, 2x batteries, 1x battery charger, 1x wall mount & 1x pair of UV safety glasses

Specifications

Additional information
